Convert NMEA data from Elfin EW10 to Wi-Fi effortlessly
Title: Transform Your NMEA 0183 to WiFi with Elfin EW10 for Less Than €10 – Easy as Pie!
Imagine sailing the seven seas with the convenience of having your marine navigation data wirelessly broadcasted to your tablet, smartphone, or onboard systems. Here's a step-by-step guide on turning your AIS equipment and other NMEA 0183 devices into a WiFi marvel using the Elfin EW10!
Unleashing the Power of NMEA 0183 to WiFi
- NMEA 0183 is a popular serial communication protocol used in marine electronics, sending data in an ASCII format.
- To convert these signals into WiFi, you'll need a device like the Elfin EW10, which reads the serial data and broadcasts it through a WiFi network. Other compatible devices, such as AMEC Camino, Em-Trak AIS, and Matsutec HA-102, typically output NMEA 0183 data via serial ports, ready to feed into your EW10.
Converting NMEA 0183 to WiFi – A Step-by-Step Journey
1. Locate Your NMEA 0183 Data Source
- Your mission is to identify the NMEA 0183 output terminals (often labeled as TX+, TX-, or similar) for devices like AMEC Camino, Em-Trak AIS, or Matsutec HA-102. Scour each device's manual for the essential details.
2. Connect the NMEA 0183 Output to Elfin EW10 Input
- The Elfin EW10 accepts NMEA 0183 input via differential RS422 or single-ended RS232 connections.
- Carefully wire your components:
- For RS422 output (differential): Connect TX+ to RX+ and TX- to RX- on the EW10.
- For RS232 output (single-ended): Link TX to RX and GND to GND accordingly.Note: Ensure all devices are powered off during wiring, and double-check polarity and pinouts in line with each device's documentation.
3. Configure the Elfin EW10
- Power up the EW10, and let's get configuring!
- Access the EW10’s web interface, usually accessible at the default IP of 192.168.100.1 (refer to the manual if necessary).
- Set your WiFi SSID, password, and wireless settings as required.
- Configure the NMEA 0183 baud rate and protocol (usually 4800 bps or 38400 bps, 8N1).
- Turn on NMEA multiplexing if you plan on connecting multiple NMEA inputs.
4. Test Your WiFi NMEA Data Stream
- Link your PC, tablet, or chartplotter to the EW10 network (WiFi) and use NMEA reader software (such as OpenCPN, iNavX, or dedicated apps) to test the live NMEA 0183 sentences streaming over WiFi.
Recommended Connections for Each Device
| Device | NMEA 0183 Output Type | Connection to Elfin EW10 | Notes ||------------------|----------------------|--------------------------|---------------|| AMEC Camino | RS422 differential | TX+ to RX+, TX- to RX- | Check polarity, power requirements || Em-Trak AIS | RS422 or RS232 | Use correct port based on device model| Em-Trak often provides RS422|| Matsutec HA-102 | RS232 single-ended | TX to RX, GND to GND | May require level shifting |
Where to Buy & How Much Can You Save?
1. Elfin EW10 - NMEA Multiplexer with WiFi Output
- Website: Elfin Marine Official Website, Amazon (select regions), West Marine, Fisheries Supply
- The Elfin EW10 is an affordable, all-in-one solution for converting multiple NMEA 0183 inputs to WiFi.
2. AMEC Camino AIS and NMEA Devices
- Website: AMEC Marine USA
- AMEC Camino offers a wide range of AIS devices and other NMEA solutions to complete your marine electronics setup.
3. Em-Trak AIS Units
- Website: Em-Trak Official Website
- Choose from various Em-Trak AIS units to upgrade your vessel with cutting-edge navigation technology.
4. Matsutec HA-102
- Website: Matsutec Official Distributor
- The Matsutec HA-102 offers high-quality block designs and NMEA 0183 outputs, making it a suitable choice for marine enthusiasts.
Takeaways and Pro Tips
- Take the time to understand polarity and pinouts in each device for successful wiring.
- Use shielded marine-grade cable for NMEA wiring to ensure quality.
- Need help with wiring diagrams or software recommendations? Just ask!
With the Elfin EW10, transforming your marine navigation data into WiFi is a breeze! Embrace the future, sail smarter, and take your navigational experience to the next level!
- To harness the power of data-and-cloud-computing, connect your modern gadgets like tablets and smartphones to the Elfin EW10 WiFi network to view navigation data streaming wirelessly from NMEA 0183 devices.
- As you seamlessly integrate the Elfin EW10 with your favorite navigation devices such as AMEC Camino, Em-Trak AIS, and Matsutec HA-102, you'll leverage advanced technology to optimize your sailing experience, turning your vessel into a connected gadget paradise.
