Crafting a Personalized FPGA Development Board utilizing Zynq-7000 SoC from scratch

Rich constructs a custom development board, integrating the AMD Zynq-7000 System on Chip (SOC) and accompanying peripherals in a 23-video series on YouTube. This SOC, which combines FPGA-based logic with ARM-based processing, is extensively tested throughout the build process.

,   and  Administrator
3 min read
Rich constructs a development board for the AMD Zynq-7000 System-on- Chip, integrating the SoC and...
Rich constructs a development board for the AMD Zynq-7000 System-on- Chip, integrating the SoC and its peripherals in a sequence of 23 YouTube videos, demonstrating its capabilities. The Zynq, featuring a combination of digital signal processing and programmable logic, is subjected to this crafting process.

Crafting a Personalized FPGA Development Board utilizing Zynq-7000 SoC from scratch

Unleashing the AMD Zynq-7000 SoC's Potential

YouTube user [Rich] has tantalized tech enthusiasts once more, this time by crafting a custom development board around the AMD Zynq-7000 SoC and its various peripherals. For those uninitiated, the Zynq-7000 is a unique piece of silicon, boasting both FPGA and CPU components. Despite having been around for a while, its non-mainstream status means we don't see nearly enough projects showcasing its capabilities.

[Rich] dives headfirst into the nitty-gritty, addressing everything from power management to HDMI, USB, DDR RAM, and everything in between. By the end, he even manages to boot PetaLinux on his homebrewed setup.

It's important to note that the Zynq-7000 SoC used by [Rich] was a Xilinx part, but as a result of AMD's recent acquisition of Xilinx, the Zynq-7000 family continues to be a favorite in innovative projects and frameworks, primarily where hardware-software co-design and real-time processing are essential.

We've encountered [Rich] before, like when we checked out his Arduino-powered USB mouse for a homebrew computer back in 2021. To see him take things to the next level, don't miss his follow-up playlist: Building on my Zynq-7000.

Want to dip your toes into FPGA technology without diving headfirst? Check out how to craft a 6809 CPU on an FPGA for a more manageable introduction. For true beginners, you might want to consider boot camp.

Special thanks to [Alex] for the tip!

Beyond DIY: Current AMD Zynq-7000 SOC Projects

Curious about the amazing things the AMD Zynq-7000 SoC can accomplish in the hands of experts? Take a look at the following notable projects and frameworks currently utilizing this versatile SoC:

1. PandABlocks Framework for Beamline Orchestration

The PandABlocks framework is designed to support the Zynq-7000-based PandABox hardware platform, serving as the backbone for orchestrating motion systems and detectors in beamline scanning applications at prominent research facilities.

Key Features:- Flexible FPGA gateware- Linux kernel and root filesystem for the Processing System (PS)- TCP server and web-based UI for dynamic configuration of functional block connections[5]

2. Real-Time Feature Extraction and Structure-from-Motion

Dedicated research teams employ the Zynq-7000 SoC for real-time ORB feature extraction, the initial stage of a structure-from-motion (SfM) pipeline. This technology finds application in robotics, augmented reality, and autonomous navigation, leveraging the SoC’s ability to handle real-time visual data processing[3].

3. Radar Signal Processing and Diagnostics

The Zynq-7000 SoC is used for real-time radar signal processing and diagnostics, with applications in sectors such as automotive, defense, and medical imaging, thanks to its combination of hardware acceleration and flexible software control[4].

4. High-Level Synthesis (HLS) IP Core Benchmarking

The AHA IP cores project uses Zynq-7000 platforms to benchmark and rapidly prototype new hardware accelerators using High-Level Synthesis (HLS) tools. This streamlines the development and evaluation of custom compute-intensive hardware for a wide range of applications[2].

In Conclusion

The AMD Zynq-7000 SoC remains a go-to solution for projects demanding real-time hardware acceleration, reconfigurability, and tight integration between hardware and software. Its applications span scientific research, computer vision, radar, and hardware acceleration benchmarking, with active development and deployment across academia and industry[2][3][5].

  1. In the realm of scientific research, the AMD Zynq-7000 SoC is utilized in the PandABlocks Framework for Beamline Orchestration, a system that uses the SoC's FPGA gateware and Linux kernel for motion systems and detector control in high-precision applications.
  2. Additionally, the Zynq-7000 SoC is employed by dedicated research teams for real-time ORB feature extraction, a crucial step in structure-from-motion (SfM) pipelines, which have applications in robotics, augmented reality, and autonomous navigation, taking advantage of the SoC's ability to process real-time visual data.
