Design Principles for Flex Circuit Boards (Part 1): Pre-Design Factors to Consider
In the realm of electronic components, flexible printed circuit boards (FPCs) have emerged as a versatile solution for various industries due to their compact size, 360° bendability, and resistance to vibration. These advantages make them ideal for use in medical devices, the automotive industry, and space applications.
FPCs offer indirect cost savings through the absence of wire harnesses, simplifying the assembly process, reducing labor costs, and assembly time. By consolidating multiple circuit boards, wire harnesses, and connector pairs, FPCs can lead to significant cost reductions. Eliminating bulky connectors also reduces the number of potential points of failure, resulting in improved reliability and longevity of the product.
The construction of FPCs involves several materials. The base substrate typically includes polyimide, a material known for its excellent thermal stability up to 400°C and flexibility. Polyester is another common substrate material, although it is less durable under high temperatures compared to polyimide.
Conductive layers in FPCs are usually made of copper foil, with rolled annealed copper preferred for dynamic applications due to its ductility. In high-density designs, electro-deposited copper is used. Adhesives bond the copper to the substrate, though adhesive-less processes are gaining popularity to reduce thickness and enhance flexibility. Overlay, made of polyimide with an adhesive layer, protects the traces from environmental damage.
Incorporating stiffeners may be necessary based on the application's mechanical requirements, size constraints, and budget considerations. Materials like FR4 or polyimide are added to provide rigidity and support during component assembly.
Designing with the stack-up in mind and consulting with the contract manufacturer regarding design rules, materials, and specifications is crucial. Following standard design guidelines can help cut overall board cost, and IPC and mil-grade standards exist for flex and rigid-flex boards.
Vern Solberg, a flex PCB expert, recommends determining the type of application, including the number of times the PCB will flex, whether it is dynamic or static, the bend radius, and the thickness of the overall PCB before the design stage begins. Customizing the design to align perfectly with the requirements of the application is necessary, and exploring alternatives like rigid-flex configurations may become necessary for applications that demand more than a single-layer flex.
Flexible printed circuits can be tailored to fit any device shape, facilitating seamless integration and enhanced functionality. Placing the flex layer within rigid layers is an important DFM guideline, and multilayer boards with greater complexity are in demand as pin counts rise and thousands of I/Os are incorporated into some devices.
When designing a flex circuit board, it is essential to follow the IPC standards such as IPC-2223, 4203, 4204, 4205, and 6013. Always consult your CM before finalizing the materials to ensure the best possible outcome for your FPC project.
The material selector in the design phase for flexible printed circuit boards (FPCs) should consider the type of substrate, such as the durable polyimide or the more cost-effective polyester. Additionally, the controlled impedance and flexibility of the conductive layers can be optimized by selecting appropriate materials like rolled annealed copper or electro-deposited copper. Adhering to technology recommendations, such as understanding application requirements and following IPC standards, ensures the best possible outcome for FPC projects.
