Breaking Out a 0.5mm BGA: Key Design Considerations
Manufacturing a printed circuit board (PCB) with a 0.5mm ball grid array (BGA) requires careful planning and adherence to specific design rules to ensure successful breakout and avoid manufacturing defects.
Annular Ring Calculation:
The annular ring, the copper ring surrounding the drilled hole, plays a crucial role in preventing breakout and opens. For plated through holes (PTH), a minimum annular ring of 6 mils is recommended. To achieve this, the pad diameter should be at least 9 mils, ensuring a sufficient annular ring on every side.
Trace Width and Spacing:
The minimum trace width should be 3 mils, as specified. Maintain at least 3.5 mils for annular rings in vias, and preferably no less than 6 mils for PTH. Drill hole spacing should be at least 8 mils to prevent drill bits from breaking and to maintain mechanical strength.
Design Rules Summary:
- Drill Size: 6 mil minimum
- Via Pad Diameter: ≥ 9 mil
- Annular Ring Width: ≥ 6 mil for PTH, ≥ 3.5 mil for vias
- Minimum Trace Width: 3 mil
- Minimum Drill Hole Spacing (via-to-via): ≥ 8 mil
Additional Considerations:
Collaborate with your PCB fabricator early to confirm these design rules match their capabilities and review DFM reports. Impedance and stack-up design can be critical; 3 mil trace widths are feasible for controlled impedance with appropriate dielectric thickness and material selection. Use PCB design software with built-in design rule checks (DRC) to enforce these constraints.
Other Important Factors:
The copper spoke between the drills on a 0.5mm BGA will be 3 mils wide. The solder mask and solder paste for a BGA are also 10.68 mils. The board must be 62 mils or less thick and have no more than eight layers for the given drill-to-copper spacing to apply.
In summary, breaking out a 0.5mm BGA with 6 mil drills and 3 mil traces requires pads sized about 9 mils minimum, ensuring annular rings of at least 6 mils, drill spacing of ≥ 8 mils, and trace widths of 3 mil supported by your fab. Follow IPC or internal standards closely and confirm the design with your board house’s DFM rules to avoid annular ring breakout and ensure manufacturability.
Technology plays a significant role in ensuring the successful breakout of a 0.5mm BGA during the manufacturing process of a printed circuit board (PCB). Using PCB design software with built-in design rule checks (DRC) is essential to enforce design constraints such as minimum trace width, annular ring width, and drill hole spacing, which are vital for preventing a breakout and achieving manufacturability.
