Nintendo's upcoming Switch model undergoes detailed, multilayer CT scans, revealing its inner workings, such as the Nvidia Tegra system-on-chip in intricate detail.
The Nintendo Switch 2: A Closer Look at Gaming's Inner Workings
Eager gamers have been dissecting the Nintendo Switch 2 to see what makes this console tick. While we've got a good idea of the Switch 2's specifications, it's always fun to delve deeper and catch a glimpse of the tech wonderland inside. A recent Reddit post shared by the user Scan-of-the-month offers an enlightening sneak peek, featuring a CT scan of the Nvidia Tegra SoC, among other components.
Here's the lowdown on what you see within the Switch 2's guts:
- That big block? That's the 5220mAh battery, nestled snugly to the left of a Realtek audio codec chip.
- Wireless support? It's all thanks to a MediaTek Wi-Fi and Bluetooth module.
- Memory Boost? The console houses two SK Hynix components: a 256GB UFS storage module and two 6GB LPDDR5X RAM chips.
The CT scan reveal that really got the gaming community buzzing is the look at the Nvidia SoC. As we'd suspected, the Switch 2 is powered by a Tegra chip, labeled as GGMLX30-A1. A video in the thread provides a stunningly close-up look at the chip layer by layer.
The Switch 2's internal hardware configuration serves as a testament to modern gaming engineering. Though it largely confirmed what we expected, it's always a thrill to peek behind the curtain.
While some fans are tearing apart the Switch 2 in less than friendly ways, Scan-of-the-month's CT scan is a more peaceful exploration of the console's inner workings. In a more measured teardown, the Nintendo Switch 2's various parts, complete with the prominent Nvidia Tegra SoC, were carefully documented, piece by piece.
As for the long-term prognosis for our CT scan friend, we're not certain. But in the meantime, we're content with the insights we've gleaned from this dissection of the latest Nintendo handheld.
Stay Tuned for More Gaming Goodness
Want the latest gaming news and expert reviews delivered straight to your inbox? Subscribe to the Tom's Hardware newsletter today! You can also follow Tom's Hardware on Google News for regular updates in your feeds. Don't forget to click the Follow button!
Sources: 1. iFixit 2. Nvidia 3. TechRadar 4. PCMag 5. DSOGaming
Insights:
- The Nvidia Tegra SoC is a crucial component responsible for the console's processing capabilities, handling both CPU and GPU functions.
- The Joy-Con controllers feature a modular and detachable design, with an integrated magnetic latch mechanism that contributes to the device's portability and customization options.
- The compact and efficient internal layout of the Joy-Con controllers plays a crucial role in maintaining the device's overall compactness and usability.
- The console's various parts, such as the sticks on the Joy-Con 2s and headphone jack, are modular, making it relatively easy to dismantle and reassemble the console using basic tools.
- However, components like the game card slot and USB-C ports are not modular, requiring more complex replacement procedures.
- Battery replacement can be more challenging in the Switch 2 due to the batteries being glued down.
- Amidst the detailed exploration of the Nintendo Switch 2, it's interesting to note that the console's internal hardware configuration includes smartphones' technology, such as the MediaTek Wi-Fi and Bluetooth module for wireless support.
- Additionally, the console houses gadgets like SK Hynix's memory components, including a 256GB UFS storage module and two 6GB LPDDR5X RAM chips, signifying the advancement in technology within modern gaming gadgets.
